GT Solar wifi Bluetooth 48V Charge Controller Solar mppt 100 amps
| Battery voltage | 12/24V/36V/48VAuto |
|---|---|
| MAX pv voltage | 150V(at the lowest temperature) |
| Rated charging current | 10A 20A 30A 40A 50A 60A 80A 100A |
| Max charging current | 12V: 130W 260W 390W 520W 650W 780W 1040W 1300W |
| MIN PV voltage | 20v/40v/60v/80v |
| Reted discharge current | 10A 10A 20A 20A 30A 30A 40A 40A |
| Self-consum | ≤35mA(48v) |
| MPPT highest accuracy | 99% |
| Max charging efficiency | 97% |
| Charging control mode | Mult-stage(MPPT, absorption,float, equalication, CV) |
| Floating charge | 13.8v/27.6v/41.4v/55.2v |
| Boost charge | 14.4v/28.8v/43.2v/57.6v |
| Equalization charge | 14.6v/29.2v/43.8v/58.4v |
| LVD | 10.8V/21.6V/32.4V/43.2V |
| LVR | 12.6V/25.2V/37.8V/50.4V |
| Load control mode | Normal, light control, light and timing, timing control, reverse light control |
| Light control point control voltage | 5v/10v/15v/20v |
| Battery type | GEL, SLD, FLD and user (default),lithium battery customization, 3series 3.7v, 4 series 3.7v, 4series 3.2v, 5series 3.2v |
| Human interface | color LCD with backlight, 3 buttons |
| Storage temperature | -30°C ~ +80 °C |
| Working temperature | -20°C ~ +55 °C |
| Humidity | -30 ~ +80 °C |
| Grounding | Positive grounding |
| Communication mode | WIFI, Bluetooth, RS485 |
